1.32 Inch Round Amoeld 466*466 QSPI Interface Custom Oled Display Module

HEM-Amoled 1.32 Inch QSPI Custom Oled Display Module

The AMOLED display represents a significant advancement in visual technology, offering users a stunning and immersive viewing experience. With its remarkable features and cutting-edge specifications, this display sets new standards for visual excellence. With a diagonal length of 1.32 inches, this AMOLED display creates a compact yet powerful visual output.

The dot arrangement of the display is configured at an impressive 466*466, providing a high-resolution viewing experience. This dot matrix enables the precise rendering of images, graphics, and text, resulting in sharp and vibrant content. The high pixel density ensures that every detail is captured with utmost clarity, making it perfect for applications that require accurate and detailed visual representation.

One of the standout features of this AMOLED display is its free viewing direction. Users can enjoy an optimal viewing experience from any angle, ensuring consistent image quality and visibility. Whether viewed head-on or from different orientations, the display maintains exceptional clarity and legibility, offering a truly immersive viewing experience.

In terms of physical dimensions, the module size of the AMOLED display measures 36.35*36.35*0.5, making it compact and suitable for integration into various devices and systems. Despite its slim profile, the display's active area spans 33.55*33.55, providing ample space for displaying content while maintaining a sleek and modern aesthetic.

The AMOLED display incorporates the C05300 driver IC, which plays a crucial role in controlling and managing the display's performance. This driver IC ensures smooth operation, efficient power management, and accurate color reproduction, contributing to the overall reliability and visual excellence of the display.

Additionally, the display features the BV6802W power IC, responsible for providing stable and efficient power supply to the display. This power IC enhances energy efficiency and longevity, ensuring optimal performance and durability.

The FT6146-M00 TP IC drives the touch panel functionality of the AMOLED display, enabling precise and responsive touch input. Users can interact with the display seamlessly, whether it's tapping, swiping, or performing multi-touch gestures. The integration of touch functionality adds an extra layer of convenience and interactivity to the user experience.

The interface type of this AMOLED display is QSPI (Quad Serial Peripheral Interface), which facilitates high-speed and reliable communication between the display and the controlling device. The QSPI interface enables fast data transfer, ensuring smooth and efficient operation of the display in various applications.

The input voltage required for the display is 3.3V, providing a standard and widely compatible power supply. This input voltage ensures reliable and stable operation, contributing to the longevity and performance of the display.

The operating temperature range of the AMOLED display spans from -20℃ to 70℃, making it suitable for use in a wide range of environments and conditions. This temperature tolerance ensures that the display remains operational and reliable even in extreme temperatures or challenging operating conditions.

For storage, the AMOLED display can withstand temperatures ranging from -30℃ to 80℃, ensuring the longevity and durability of the display even during extended periods of non-use or when subjected to unfavorable storage conditions.

Luminance is a crucial aspect of any display, and the AMOLED display excels in this regard. It offers a minimum luminance of 450cd/m2 and a typical luminance of 550cd/m2. This high luminance level ensures excellent visibility and readability even in bright environments or under direct sunlight. The display produces vibrant and vivid colors, enhancing the overall visual experience.

In conclusion, the AMOLED display with a diagonal length of 1.32 inches represents a remarkable technological advancement in visual display technology. With its high-resolution dot arrangement, free viewing direction, compact module size, and ample active area, this display is well-suited

 for a wide range of applications. The integration of the C05300 driver IC, BV6802W power IC, and FT6146-M00 TP IC ensures smooth operation, efficient power management, responsive touch functionality, and seamless communication. Moreover, its broad operating and storage temperature ranges, coupled with impressive luminance levels, make it suitable for diverse environmental conditions. The AMOLED display opens up endless possibilities in visual communication and provides users with an exceptional and immersive viewing experience.

AMOLED (Active Matrix/Organic Light Emitting Diode) is an active matrix organic light emitting diode panel. Compared with traditional LCD panels in terms of display performance, AMOLED has faster response speed, higher contrast ratio, and wider viewing angle. These are the places where AMOLED is inherently better than TFT LCD. In addition, AMOLED has the characteristics of self-illumination and does not need to use backlight. board, so it can be made thinner and lighter than TFT, and saves power; there is another more important feature, AMOLED that does not need a backlight board can save the cost of the backlight module that accounts for 3~4 of the TFT LCD.AMOLED is the best display technology to replace TFT-LCD: OLED (Organic Light Emitting Diode) adopts a new type of flat display technology that stimulates luminescent materials to actively emit light by current to obtain display effects; among them, PMOLED technology with relatively simple manufacturing process is relatively mature, but It only has significant advantages in small-size applications; based on its own advantages in manufacturing process and structure, AMOLED has more obvious advantages than TFT-LCD, and is suitable for medium and large-size display fields, and is the best display technology to replace TFT-LCD , is also the mainstream trend of OLED development.

We are specialized in LCD display, including mono LCD module,TFT module and AMOLED module, which is the high and new tech enterprises in the country with the independent research and development, manufacturation and sales. It has developed as the excellent one of the medium and small-size field display terminal suppliers.

We have been focused on customized TN/STN/FSTN/VA monochorome displays,as well as small to medium sized TFT displays and oled displays for about 17 years.

We now have two complete monochrome LCD production lines, a dozen of fully automatic COG production line and the full processing capacity for COB and CTP full lamination.With a professional R&D team, Well-developed quality control system, highly effective execution and management team and a pro-innovation corporate culture. We vow to satisfy our customers by meeting the quantity and quality requirements.

A MES (Manufacturing Execution System) quality process flowchart is a visual representation of the steps involved in the manufacturing process, from raw materials to finished products, with a focus on quality control.Overall, the MES quality process flowchart helps to ensure that the manufacturing process is carried out efficiently and effectively, with a focus on quality control and customer satisfaction.

Jiangxi HEM Technology Co.Ltd.was incorporated in 2016 and finds its headquarters in Wanzai  of Jiangxi Province.

Huaersheng  invested 106,667 square meters display industrial park in 2022,which has the floorage of  12000 square matres.

Park planning: 2 panel production lines of 370mm*470mm, 6full-automatic AMOLED production lines,30 COG  full-automatic AMOLED production lines.

1.What kinds of display does HEM have?

 HEM is specializing in manufacturing TFT LCD display, Monochrome LCD display,Touch Screen, customized LCD panel, COB and COG display.

 2.How can I find the right product?

Please send us your requirements or datasheet, we will recommend our standard products, if it’s not fit, we will do the necessary adjustment & customization.

3. Do you accept sample order or small quantity order?

Yes, you can place 1.32 inch sample orders for testing first, and small quantity order as pilot production (no less than MOQ)

 4.What’s the lead time?

 Usually 3~5 days for 1.32 inch AMOLED sample orders if goods are in stock, and 4~5 weeks for mass production (basing on the quantity and particular product).

5.What’s your order process?

Evaluating the project and give quotation→confirming with the customers→customers 100% pay the tooling fee and samples cost in advance→we arrange the drawings for customer in three woking days after received the payment→customers confirm the drawings→we arrange the production of samples in two or three weeks after the customers confirm the drawings are okay→send the sample to the customers for testing→modify the design according to the customer's opinion and send the sample again until the customer is satisfied→customer 30% payment in advance→batch production
