Instrument Display Custom LCD Module Monochrome Screen For Rangefinder
Display Type:FSTN/POSITIVE
Operating Voltage:VDD:2.0~3.6V ,Vlcd:5.75V
Operating Temperature:-20℃~70℃
Storage Temperatrue:-30℃~80℃
Drive Mode:1/9D,1/4B
Viewing Direction:6:00
Polarizer Type:TRANSMISSIVE
Connector:COG/ST7567A
Interface Type:3SPI
Mo






Customized Monochrome Screen LCD Display Modules Used In Electric Equipment
Display Type:TN/POSITIVE
Operating Voltage:3.3V
Operating Temperature:-40℃~85℃
Storage Temperature:-40℃~90℃
Drive Mode:1/4D,1/3B
Viewing Direction:6:00
Polarizer Type:REFLECTIVE
Connector:PIN
Module Size:83.00*32.00*2.80
Active Area:80.00*25.00






Custom TN LCD Module Monochrome Digital LCD Display For Medical Equipment
Display Type:TN
Operating Voltage:2.6V
Operating Temperature:-10℃~60℃
Storage Temperature:-20℃~70℃
Drive Mode:1/4D,1/3B
Viewing Direction:6:00
Polarizer Typ:POSITIVE REFLECTIVE
Connector:ZEBRA
Module Size:39.50*39.50*2.80
Active Area:35.50*33.00






240*128 Mono LCD Display Industrial Control Equipment TFT LCD Module Factory
Display Type:FSTN/POSITIVE
Resolution:240*128
Operating Voltage:VDD=3.0V VOP=11.7V
Operating Temperature:-20℃~70℃
Storage Temperature:-30℃~80℃
Drive Mode:1/128D,1/12B
Viewing Direction:6:00
Polarizer Type:TRANSMISSIVE
Connector:COG/UC1638C
Module






48*48 Monochrome Graphic LCD Display Modules Applied To Kids Toys
Display Type:STN/GRAY/POSITIVE
Resolution:48*48
Operating Voltage:VDD=3.3V,Vlcd=10.0V
Operating Temperature:0℃~50℃
Storage Temperature:-20℃~70℃
Drive Mode:1/49D,1/8B
Viewing Direction:12:00
Polarizer Type:TRANSMISSIVE
Connector:COG/SC5260-G5-1
Mo






Customized Monochrome Used In Sports Equipment Segment Code Screen LCD Display Supplier
Display Type:VA/NEGATIVE
Operating Voltage:5.0V
Operating Temperature:0℃ TO +50℃
Storage Temperature:-10℃ TO+60℃
Drive Mode:1/4 DUTY 1/3 BIAS
Viewing Direction:6:00
Frame Frequency:64HZ
Front Polarizer:TRANSMISSIVE,ADHESIVE
Back Polarizer :TRANSMI






Customized Monochrome LCD Panel Segment Code Screen For Onboard Instrument
Display Type:VA/NEGATIVE
Operating Voltage:5.0V
Operating Temperature:-30℃~80℃
Storage Temperature:-40℃~90℃
Drive Mode:1/2D,1/2B
Viewing Direction:12:00
Polarizer Type:TRANSMISSIVE
Connector:COG/UC1677C
Module Size:65.20*45.20*2.30
Active Area:60






Customized Monochrome Graphic LCD Display Applied To Onboard Instrument
Display Type:VA/NEGATIVE
Operating Voltage:VDD=3.0V/VOP=7.0V
Operating Temperature:-20℃~70℃
Storage Temperature:-30℃~80℃
Drive Mode:1/4D,1/3B/≥120Hz
Viewing Direction:6:00
Polarizer Type:TRANSMISSIVE
Connector:COG/ST7075
Module Size:95.24*51.98*3.






2.0 Inch IPS 262K All O`Clock TFT Display for E-cigarettes
HEM-2.0 inch TFT Transmissive Module
1.Display type:BOE 2.0” IPS,262K
2.Resolution:240*320
3.Viewing direction:ALL
4.Drive IC:JD9851
5.LUMINANCE=350cd/㎡(MIN);
X=0.297±0.02, Y=0.332±0.02
6.LED:If=20.0mA/LED(CONSTANT CURRENT),
7.OPERATING TEMP:-20℃
