1.47 Inch ST7789V3 Mini LCD Screen MCU-8BIT 172*320dot LCD Display Distributor
Display Type：1.47'',TRANSMISSIVE,172*320
Viewing Direction：FREE
Dot arrangement：172*320 dot
Active Area：17.39*32.35 mm
Driver IC：ST7789V3
Interface Type：MCU-8BIT
LED/Connection method/Current：3-LED/60MA
Luminance：350
1.91 Inch 320*380 TFT Custom LCD Screen 31.20*37.05mm Small Digital Display
Display Type：1.91''TFT,TRANSMISSIVE
Structure：ZC
Dot arrangement：320RGB*380
Module Size：36.30*40.40*2.95 mm
Active Area：31.20*37.05 mm
Luminance：300cd/m2(TYP)
Driver IC：GC9B71
Operating Temperature：-20℃~70℃
Storage Temperature：-30℃~80℃
2.4 Inch 240*320 TFT LCD 16.7M Colors Transmissive Screen Display
Display Type：A-SI,TFT-LCD,16.7M COLORS
Diagonal length：2.4 inch
Viewing Direction：ALL O`CLOCK
Dot arrangement：240*320 dot
Display Mode：TRANSMISSIVE
Module Size：85.43*73.32*3.36 mm
Active Area：36.72*48.96 mm
VDD：2.5~3.3V
Luminance：240(TYP)
Driver
1.83 Inch 240*284IPS 262K ST7789P3 TFT Color Monitor Custom LCD Supplier
Display Type：1.83 262K,a-SI,TFT,HADS
Dot arrangement：240(R.G.B)*284
Module Size：35.12*43.12*3.49
Active Area：29.52*34.93
Pixel Size：0.123*0.123
Luminance：650(MIN)
Driver IC：ST7789P3
Interface Type：4SPI
2 Inch IPS 262K Monitor ST7789V3 Custom TFT Displays
Display Type：2.0'' 240*320 IPS,262K
Active Area：30.60*40.80
Viewing Direction：ALL
Luminance：350(MIN)
Interface Type：4SPI
Connection Mode：Welding
Driver IC：ST7789V3
TFT1.39 Inch LCD Panel 360*360 QSPI GC9B71 Display Module
HEM-1.39 inch TFT Transmissive Module
Display Type：TFT/Transmissive
Size：1.39inch
Dot arrangement：360*360
Module size：37.80*39.82*1.46
Active Area：35.31*35.31
Operating Temp：-20℃ ~70℃
Storage Temp：-30℃ ~80℃
Optimum Viewing Angle：Free
Luminance：50
2.8 Inch 240*320 IPS TFT LCD Display Modules Various Sized Manufacturers
HEM-2.8 inch 240*320 IPS TFT LCD Display
LCD Size：2.8inch
Resolution：240*320
Operating Temp：-20℃~70℃
Storage Temp：-30℃~80℃
Driver IC：ST7789T3
Optimum viewing angle：FREE
Backlight：2 CHIP WHITE LED;(If=80mA;Vf=2.8~3.2V)
Unmarked Tolerance：±00.2mm
7 Inch TFT LCD Monitor 1024*600 TFT Display Module
HEM-7.0 inch TFT Transmissive Module
LCD Size：7.0inch
Resolution：1024*600
Luminance：250(MIN),300(TYP)
Interface Type：RGB
Color：16.7M
Connection Mode：Plugging in
Driver IC：GH8555BL
5 Touch Display TFT Monitor TFT LCD Display Panel
HEM-5.0 inch TFT Transmissive Module
LCD Size：5.0inch
Resolution：720*1280
Luminance：350(MIN),400(TYP)
Interface Type：Mipi 4 channels
Color：16.7M
Connection Mode：B=B
Driver IC：JD9365D
